Designed for under the sink point-of-use applications with a maximum flow rate of .5 gpm. Amperage draw: 29, required breaker: 30, required wire: 10 AWG, connection fitting: 1/2" MPT. Dimensions: 7" x 11" x 3". For single faucet application.

RHEEM 30GAL WATER HEATR 120V UPR

RHEEM 30G WATER HEATR 240V UPRIG

Product Description

Efficiency: .85 - .93 EF - Isolated tank design reduces conductive heat loss - Registered stainless steel lower heating element - Performance: FHR: 42 - 99 gallons, based on gallon capacity - Recovery rate is 21 gallons at a 90 degree Fahrenheit rise - System Sentinel (Available on selected models) - Exclusive diagnostic system with glowing LEDs that verify heating element operation. LEDs pin point the exact location of functioning or non-functioning heating elements.

Rheem Classic, 65 Gal, Electric, DE, 240 Volts, Nonsim 2-Wire, 4500 Watts/4500 Watts, 6 Year Tank/6 Year Parts/1 Year Labor, Installed T&P, Upper HWC / Lower LWSS

Efficiency: .85 - .93 EF - Isolated tank design reduces conductive heat loss - Registered stainless steel lower heating element - Performance: FHR: 42 - 99 gallons, based on gallon capacity - Recovery rate is 21 gallons at a 90 degree Fahrenheit rise - System Sentinel (Available on selected models) - Exclusive diagnostic system with glowing LEDs that verify heating element operation. LEDs pin point the exact location of functioning or non-functioning heating elements.

RHEEM 120G WATER HEATR 240V UPRI

Features:
Electric junction box located above heating elements for easy installation
Over-temperature protector cuts off power in excess temperature situations
Automatic thermostat keeps water at desired temperature
EverKleen(TM) self cleaning device fights harmful sediment build-up with a high-velocity spiraling water stream - helps operating efficiency by saving energy, money and improving tank life
Enhanced-flow brass drain valve
Temperature and pressure relief valve included
Low lead compliant

Electric Water Heater, Residential, Water Heater Design Whole House, Tank Capacity - Plumbing 50.0 gal, Voltage - Water Heaters 240, Phase - Water Heaters 1, 4,500 W Total Watts, Overall Height - Water Heaters 58 5/8 in, Jacket Dia. 20 3/8 in, Recovery @ 90 F Rise 21.0 gph, Height to T and P Opening 58 5/8 in

Product Description

Efficiency: .85 - .93 EF - Isolated tank design reduces conductive heat loss - Registered stainless steel lower heating element - Performance: FHR: 42 - 99 gallons, based on gallon capacity - Recovery rate is 21 gallons at a 90 degree Fahrenheit rise - System Sentinel (Available on selected models) - Exclusive diagnostic system with glowing LEDs that verify heating element operation. LEDs pin point the exact location of functioning or non-functioning heating elements.

Certifications and Listings
UL Listed
Commercial/Residential
Residential
Finish Family
Gray
Fuel Type
Electric
Indoor/Outdoor
Indoor
Nominal Tank Capacity (gallons)
47
Pack Size
1
Product Depth (in.)
26.25
Product Height (in.)
34
Product Weight (lb.)
149
Product Width (in.)
26.25
Certifications
UL

RHEEM 38G WATER HEATR 220V L/BOY
